THERMALTAKE View 380 XL TG ARGB, CASE, ATX, 120mm R x3, 120mm, AIO 360mm, air 160mm, GPU 420mm, 3.5”, Type-C, USB 3.0x2, Au

Specification

P/N: CA-11E-00M1WN-00
Series: View
Model: View 380 XL TG ARGB
Dimensions (height x width x depth): 471 x 288 x 469 mm
(18.54 x 11.34 x 18.46 inches)
Panel: 4mm tempered glass x 2
Color: Black
Material: SPCC
Cooling System: Right (Inlet): 120 x 120 x 25 mm ARGB Lite Inverted Fan (1000 RPM, 21.9 dBA) x 3
Rear (exhaust): 120 x 120 x 25 mm ARGB Lite fan (1000 rpm, 22.3 dBA) x 1
Drive bays: 1 x 3.5”, 2 x 2.5” or 3 x 2.5”
Expansion slots: 8
Motherboards: 6.7” x 6.7” (Mini ITX), 9.6” x 9.6” (Micro ATX), 12” x 9.6” (ATX)
Input/Output Port: USB 3.2 (Gen 2) Type-C x 1, USB 3.0 x 2, HD Audio x 1
Power supply: Standard PS2 power supply (optional)
Fan base
Top:
3 x 120 mm, 2 x 120 mm, 1 x 120 mm,
2 x 140 mm, 1 x 140 mm
Right:
3 x 120 mm, 2 x 120 mm, 1 x 120 mm
Rear: 1 x 120 mm
Bottom: 3 x 120 mm, 2 x 120 mm, 1 x 120 mm
Radiator support
Top:
1 x 360 mm, 1 x 240 mm, 1 x 120 mm
1 x 280 mm, 1 x 140 mm
Right: 1 x 360 mm, 1 x 240 mm, 1 x 120 mm
Rear: 1 x 120 mm
CLEARANCE CPU cooler maximum height: 160 mm
VGA maximum length: 420 mm
Maximum power supply length: 180 mm
